Low capacity high rate polymer type batteries
Technology and application areas:
Nominal voltage: single cell voltage 3.7V;
Capacity: According to different market segments product selection and design requirements;
Features: high capacity, long cycle life, good low temperature performance, environmental protection, safety and excellent performance;
Practical areas: digital, Bluetooth battery, mobile power, instrumentation, lighting batteries, speakers batteries, portable batteries, batteries and other products worn areas.
Low capacity high rate polymer type batteries Specification Table
电芯型号 | 外型尺寸 | 内阻 （mΩ） | 容量 (mAH) | 电压 （V） | 温度（℃） | 重量 （g） | 下载 | |||
长（mm） | 宽（mm） | 高度（mm） | 低温 | 高温 | ||||||
ICR053048 | 47±0.1 | 29±0.1 | 4.9±0.3 | 33 | 800 | 3.7 | -40 | 75 | ||
ICR053048R | 47±0.1 | 29±0.1 | 4.9±0.3 | 35 | 1000 | 3.7 | -30 | 75 | ||
ICR103450 | 49±0.1 | 33±0.1 | 9.9±0.3 | 25 | 1100 | 3.7 | -40 | 75 | ||
ICR103450R | 49±0.1 | 33±0.1 | 9.9±0.3 | 35 | 1200 | 3.7 | -40 | 75 | ||
